Product Overview

This SWMS covers pipe-laying work from planning and locating services through to excavation, pipe installation, testing, backfilling and site reinstatement. It supports planning and risk management for services, traffic, plant, trench conditions, suspended pipes, sewer exposure and open excavations.

Activities & Specific Tasks Covered

This document includes task-specific risk controls for:

Plan the work and locate underground services
Establish site access and traffic controls
Position and inspect plant and lifting attachments
Excavate trenches and manage spoil, water and access
Prepare bedding and handle PVC pipes or columns
Install PVC pipe in deep trenches
Lay sewer pipes, joints and stormwater road crossings
Test pipework and carry out backfilling
Reinstate the site and manage remaining excavation or traffic hazards

Who is this for?

For contractors, workers, supervisors and businesses carrying out pipe-laying activities.

Specific Job Steps & Hazards Covered

Job Step / Activity	Potential Hazards
Plan work and locate services	Underground services strike Energised electrical cable Gas or fuel release Unplanned sewer exposure Incorrect pipe alignment
Establish site and traffic controls	Public vehicle strike Plant-pedestrian interaction Unauthorised entry Worker struck by reversing vehicle Poor site access
Position and inspect plant	Plant roll-over Swinging counterweight Hydraulic failure Overhead service contact Uncontrolled lifting attachment
Excavate trench and manage spoil	Trench collapse Fall into excavation Falling spoil Plant entering trench Water ingress Underground services strike
Inspect deep trench access	Collapse in trench over 1.5 m Restricted egress Hazardous atmosphere Fall from ladder Falling objects
Prepare bedding in shallow trench	Manual handling strain Dust exposure Compactor strike Unstable trench edge Uneven bedding
Handle PVC pipes and columns	Musculoskeletal injury Crush from rolling pipe Sharp pipe edges Pipe stack collapse Suspended load strike
Install PVC pipe in deep trench	Trench collapse Crush from suspended pipe Pinch points at joints Hazardous atmosphere Loss of communication Fall into trench
Lay sewer pipes and joints	Sewer gas exposure Biological contamination Solvent vapours Pipe misalignment Manual handling strain Existing sewer surcharge
Lay stormwater road crossings	Traffic strike Large pipe crush Water inundation Plant collision Unstable road pavement Public access
Test pipework and backfill	Stored-pressure release Pipe displacement Compactor strike Dust and noise Trench collapse during works
Reinstate and demobilise site	Residual open excavation Plant-pedestrian interaction Trips from waste materials Unsecured plant Traffic exposure

Need to add specific site requirements?

Use the BlueSafe Portal to tailor this SWMS with site-specific details, job steps, hazards, controls and responsibilities before work starts.

Acceptance Guaranteed: If your client or principal requests changes during document review, BlueSafe will help revise the document at no extra cost and support resubmission until it is accepted.

Legislation & References

The template includes references relevant to the documented work, including:

Applicable Commonwealth, state or territory WHS/OHS legislation and regulations.
Model Code of Practice: Excavation Work — guidance for service information, excavation collapse, falls, access, atmospheric hazards and trench controls.
Model Code of Practice: Construction Work — guidance for construction planning, consultation, coordination and SWMS.
Model Code of Practice: Managing the Risks of Plant in the Workplace — guidance for mobile plant and pedestrian separation.
Model Code of Practice: How to Manage Work Health and Safety Risks — guidance for applying the hierarchy of controls.
Model Code of Practice: Confined Spaces — apply where a trench, pit or connected sewer is a confined space.
AS/NZS 2032 Installation of PVC pipe systems; AS/NZS 2566 Buried flexible pipelines; AS 3500 Plumbing and drainage; AS 4744.1 Steel shoring and trench lining; AS 2550.1 Cranes—Safe use; AS 1418.8 Cranes, hoists and winches—Special purpose appliances; AS 1742.3 Traffic control devices for works on roads; AS/NZS 2865 Confined spaces.
Model WHS laws and model Codes of Practice are guidance unless adopted or otherwise given legal effect in the relevant jurisdiction.

Standard SWMS Features (Click to Expand)

Task-specific job steps, hazards and control measures
Initial and residual risk ratings
Assigned responsible persons for each job step
Plant, equipment and PPE requirements where applicable
Permits, qualifications and high-risk construction work details where applicable
Worker consultation, sign-off and review sections
