Name: Electric Welding Arc MIG TIG and Spot Welding SWMS
Brand: BlueSafe Online
SKU: prod_01KBPKQXPA0W809KW817XS15A5
Price: 79.50 AUD
Availability: InStock

Product Overview

This SWMS covers preparation, area controls, equipment setup, welding, post-weld treatment and clean-up for arc, MIG, TIG and spot welding. It supports work planning and risk management for electrical energy, arc radiation, fumes, fire, gas cylinders, hot materials and moving equipment.

Activities & Specific Tasks Covered

This document includes task-specific risk controls for:

Plan the welding work
Establish the welding area
Control fire and explosion hazards
Inspect electrical equipment
Set up gas cylinders
Set ventilation controls
Check personal protective equipment and screens
Position workpieces safely
Perform manual arc welding
Operate TIG and MIG equipment
Operate resistance welders and robot welding cells
Conduct post-weld treatment, clean up and sign off

Who is this for?

For contractors, workers, supervisors and businesses carrying out electric welding activities.

Specific Job Steps & Hazards Covered

Job Step / Activity	Potential Hazards
Plan welding work	Incorrect process selection Toxic coatings Inadequate worker competence Unplanned fire exposure
Establish welding area	Arc flash exposure Unauthorised entry Fire spread Slips and trips
Control fire and explosion	Ignition of combustibles Flammable vapour ignition Cylinder explosion Hidden smouldering fire
Inspect electrical equipment	Electric shock Electrocution Damaged leads Electrical fire
Set up gas cylinders	Cylinder fall Gas leak Asphyxiation Regulator failure
Set ventilation controls	Welding fumes Ozone exposure Metal fume fever Oxygen displacement
Check PPE and screens	Arc eye UV skin burns Molten metal burns Inadequate respiratory protection
Position workpieces safely	Crush injury Manual handling strain Falling workpiece Hot surface contact
Perform manual arc welding	Arc radiation Electric shock Welding fumes Molten spatter Fire
Operate TIG and MIG equipment	Tungsten contamination Shielding gas release High-frequency ignition UV radiation
Operate resistance welders	Crush from electrodes Electrical energy release Burns from electrodes Ejected hot metal
Operate robot welding cells	Robot strike Unexpected start-up Crush at fixtures Arc flash escape
Conduct post-weld treatment	Hot metal burns Heat stress Grinding particles Fume from heated coatings
Clean up and sign off	Smouldering waste Hot debris Sharps and offcuts Residual gas pressure

Need to add specific site requirements?

Use the BlueSafe Portal to tailor this SWMS with site-specific details, job steps, hazards, controls and responsibilities before work starts.

Acceptance Guaranteed: If your client or principal requests changes during document review, BlueSafe will help revise the document at no extra cost and support resubmission until it is accepted.

Legislation & References

The template includes references relevant to the documented work, including:

Applicable Commonwealth, state or territory WHS/OHS legislation and regulations.
Model Code of Practice: Welding processes, including risk management for fumes, radiation, electrical risks, fire, heat, gases, ventilation and PPE.
Model Code of Practice: Managing risks of hazardous chemicals in the workplace.
Model Code of Practice: Managing electrical risks in the workplace.
Model Code of Practice: How to manage work health and safety risks.
Model Code of Practice: Confined spaces, where applicable.
AS 1674.1 Safety in welding and allied processes—Fire precautions.
AS/NZS 60974 series Arc welding equipment.
AS/NZS 3957 Light-transmitting screens and curtains for welding operations.
AS/NZS 1715 Selection, use and maintenance of respiratory protective equipment; AS/NZS 1716 Respiratory protective devices.
AS/NZS 1337.1 Eye and face protection; AS/NZS 2161 series Occupational protective gloves; AS/NZS 2210.3 Safety footwear; AS/NZS 1270 Hearing protectors.
AS 4332 The storage and handling of gases in cylinders.

Standard SWMS Features (Click to Expand)

Task-specific job steps, hazards and control measures
Initial and residual risk ratings
Assigned responsible persons for each job step
Plant, equipment and PPE requirements where applicable
Permits, qualifications and high-risk construction work details where applicable
Worker consultation, sign-off and review sections
